P&S Wave μSeismic Tool
High-Resolution Seismic Velocity Measurement
The P&S Wave μSeismic Tool is designed for simultaneous measurement of P-wave (compressional) and S-wave (shear) velocities, offering improved accuracy and resolution compared to other seismic methods. Engineered for versatility, the tool performs exceptionally well in both shallow, slower formations and deeper, high-velocity formations.
This tool features two receiver modules, each equipped with transducers specifically designed for P-waves and S-waves. The P-wave detector uses a piezoelectric device, while the S-wave detector is a geophone. Its dipole energy source generates strong shear waves by directing energy pulses perpendicular to the borehole wall, ensuring reliable seismic measurements.
The acquired data is recorded in the industry-standard SEG2 file format, ensuring compatibility with established analysis tools. Please note that this tool is suitable for fluid-filled, unlined boreholes.analysing these formations with precision.
Key Features
Specifications
- Dimensions: 4.1m or 5.0m (length) x 50mm (diameter)
- Weight: 14kg
- Acquisition Period: Variable (5–80ms)
- Maximum Temperature: 80°C
- Maximum Pressure: 50 Bar
Logging Conditions
- Centralised operation required
Borehole Compatibility
- Diameter Range: 75–300mm
- Environment: Suitable for water- or mud-filled boreholes
- Lining: Compatible with unlined boreholes
The P&S Wave μSeismic Tool is an advanced solution for seismic velocity analysis, offering exceptional accuracy and versatility. Its robust design and high-performance capabilities make it ideal for geophysical, hydrogeological, and geotechnical investigations.
